Our wide format eco solvent printer is a modern digital printing machine to reproduce digital images or files onto different media such as banners, vinyl, coated PP and PVC film etc. Offers quick operation, precise color control and is ideal for long & short production runs. It is known for durability and provides consistent performance for an extended period. The print head has versatile capability in handling various media and produces vibrant colors. The advanced technology and versatility make it ideal for many digital printing industries where accurate color reproduction is crucial.
Model: AC1802S / AC1803S
| Model | AC1802S | AC1803S |
|---|---|---|
| Print Head | Dual Epson i3200 E1 print heads | Three Epson i3200 E1 print heads |
| Technology | Drop-On-Demond Piezo with variable dot | // |
| Ink | Eco-solvent ink (2 years outdoor duribility) | // |
| Color Config. | K.C.Y.M. | // |
| Ink Supply System | Bulk ink supply system with ink cartridges | // |
| Ink Tank | 1000ml | // |
| Printing Width | Max.1800mm | // |
| Media Type | Banner, Coated PP, Vinyl, PVC film...... | // |
| Roll Diameter | Max. 300mm | // |
| Roll Weight | Max. 50kgs | // |
| Core Diameter | 3in (76.2mm) or 2in (50.8mm) | // |
| Printing Speed Draft | 360x1200dpi - 60m2/h | 360x1200dpi - 78m2/h |
| Printing Speed Production | 360x1800dpi - 43m2/h | 360x1800dpi - 62m2/h |
| Printing Speed Hi-resolution | 720x1200dpi - 30m2/h | 720x1200dpi - 45m2/h |
| Printing Speed Photo | 720x1800dpi - 21m2/h | 720x1800dpi - 31m2/h |
| Data Interface | USB 2.0 | // |
| Working Environment | Temp.23ºC~29ºC, Humidity: 50%~80% | // |
| Software | PhotoPRINT / ONYX (Optional)... + GZ Printer Manager | // |
| Power | Single phase, 50Hz/AC, 220V±10%,6.7A(Printer) + 8.118A (IR Dryer) | // |
Packed/Installed Size | LxWxH(mm): 3500x850x7700 / 3126x924x1396 | // |
| N.W./G.W. | 368kgs/268.5kgs | // |
Print Head
The Epson i3200 E1 print head allows for precise control over ink droplet size and placement by piezo variable dot technology. It gives uniform colour distribution and reduces the risk of clogging.
Drop On Demand with Piezo Variable
The drop on demand piezo variable dot technology generates precise ink droplets which vary in size, resulting in high-resolution prints with smoother gradients and sharper details.
IR Dryer
The efficient infrared dryer uses infrared radiation to rapidly dry and cure the printed ink on various media substrates. The dryer efficiently evaporates the ink and speeds up the process. It reduces the risk of smudging, maintains the quality of the output and enables faster processing.
AR Taking Up System
The wide format eco solvent printer has an AR taking up system that uses air pressure to securely hold and unwind the printing material. It ensures controlled tension, minimizing material wastage, enables consistent and smooth feeding of the substrates.
RIP Software
PhotoPRINT/ONYX with GZ printer manager is a raster image processor (RIP) software which is used in the wide format digital printing industry. It excels in preparing & optimizing graphics, advanced nesting and a user-friendly interface that simplified the print workflow.
