Our vacuum press machine is used to make different shapes with a highly elastic silicone material membrane. It is designed with a heating system that allows for preparing the material and forming solid surfaces into shapes. It is ideal for shaping the panel from a variety of materials by configured suction and reliable vacuum pumps. The accurate cycle timers & vacuum controls deliver the perfect performance and make a stack of materials with variable sizing & heights based on the demands. The vacuum press machine provides high-quality output, energy-efficient oil-lubricated vacuum pumps and combined thermo heating & forming unit.
Model: VP-1330
| Model | VP-1330 |
|---|---|
MACHINE CONSTRUCTION | |
| Overall dimensions: | approx. 3400 x 1750 x 1100 mm |
| Dimensions inside the frame: | approx. 2880 x 1280 mm |
NATURAL RUBBER MEMBRANE | |
| Material: | natural rubber NR |
| Dimensions: | 3100 x 1500 x 2 mm |
| Heat resistance: | up to + 130 °C |
| Elongation at tear: | 600% |
| Material hardness: | 40 Shore-A |
| Colour: | grey |
SILICONE MEMBRANE ECONOMY | |
| Material: | Silicone |
| Dimensions: | 3100 x 1500 x 2 mm |
| Heat Resistance: | up to + 230 °C |
| Elongation at tear: | 700% |
| Material Hardness: | 40 Shore-A |
| Colour: | white/transparent |
SILICONE MEMBRANE HIGH-PERFORMANCE | |
| Material: | silicone |
| Dimensions: | 3100 x 1500 x 2 mm |
SILICONE MEMBRANE HIGH-PERFORMANCE | |
| Heat resistance: | up to + 230 °C |
| Elongation at tear: | 700% |
| Material hardness: | 40 Shore-A |
| Colour: | Transparent |
MEMBRANE FAST-CHANGE SYSTEM, EVERY MEMBRANE IS SUITABLE, INCL. FIXING BOLTS & PROFILES, PHENOLIC RESIN WORKING SURFACE | |
| Material: | Phenolic resin laminated plywood |
| Heat resistance: | up to + 160 °C |
| Suction points: | up to 70 |
25 M³ HIGH-PERFORMANCE VACUUM PUMP | |
| Type: | Dry running rotary vane pump |
| Air suction speed: | 25 m³/h |
| Pressure: | up to 9 t/m² |
40 m³ high-performance vacuum pump | |
| Type: | Dry running rotary vane pump |
| Air suction speed: | 40 m³/h |
| Pressure: | up to 9 t/m |
80 M³ HIGH-PERFORMANCE VACUUM PUMP | |
| Type: | Dry running rotary vane pump |
80 M³ HIGH-PERFORMANCE VACUUM PUMP | |
| Air suction speed 80 m³/h | Air suction speed 80 m³/h |
| Pressure: | up to 9 t/m² |
CONTROL UNIT (VERTICAL OPENING) | |
| Pressure monitoring: | analogue vacuum pressure gauge |
| Temperature control: | digital |
| Heating time control: | digital |
VACUUM PRESSURE CONTROL: MECHANICAL VACUUM PRESSURE REGULATOR | |
| Control range of vacuum pressure: | 200 - 900 mbar rel. |
DIGITAL FESTO VACUUM PRESSURE CONTROL | |
| Control range of vacuum pressure: | Precisely 20 - 900 mbar rel. (variable) incl. 200 l vacuum tank |
VERTICAL OPENING MECHANISM | |
| Type: | pneumatic |
| Pneumatic cylinder: | 4 pcs. |
| two-hand safety operation | two-hand safety operation |
| Overall dimensions: | approx. 4000 x 2000 x 1800/2400 mm |
| Stroke: | approx. 650 mm |
HEATING DRAWER | |
| Usable area: | approx. 2600 x 1200 mm |
| Material thickness: | 0 - 70 mm |
| Heating power of the CHS heating system: | 16 kW | 400 V | 50/60 Hz |
| Circulating hot air fans: | 2 pcs. |
| Electronic temperature control: | up to + 230 °C |
| Pull-out working surface with grating: | 30 x 30 mm |
PERFORATED STAINLESS STEEL SHEET | |
| Perforation: | 5 mm |
| OVERALL DIMENSIONS: | APPROX. 2000 X 1000 X 2 MM |
The transparent silicone membrane offers the unmatched output, suited for the flat pressing of uneven materials and helps to pressurize the mold to take out its shape that removing air from the chamber. This process is very gentle, involves hearing, stretching & vacuuming over a mold and using reliable vacuum pumps & its variable pressure adjustment.
