The solvent printer 5.3 meter uses solvent-based ink that can print on a wide range of substrates including banner, frontlit, backlit and film. It makes prints durable, suitable for indoor & outdoor applications and ideal for large-scale projects. Produces vibrant, long-lasting prints with a wide color gamut and is resistant to fading, scratching or weathering. The solvent printer 5.3 meter has robust media handling capabilities, accommodating rolls of various widths and thicknesses. Includes an instant drying system to quickly evaporate the solvent from the ink which helps for faster production.
Model: GZH5306SG
| Model | GZH5306SG |
|---|---|
| Print Head | 6 Starfire 1024 print heads staggered in 3 rows (1 head 2colors) |
| Ink | C.M.Y.K solvent / eco-solvent |
| Ink Supply System | GnTek negative pressure with 5L ink tanks |
| Printing Width | Max.5300mm |
| Media Type | Banner, Frontlit, Backlit, Film…... |
| Media Delivery System | Multi-rolls media feeding system with rubber feeding roller. |
| Drying System | Pre, mid and extended heater IR dryer |
| Printing Speed | 300x400dpi (2pass) 435m2/h |
| Printing Speed | 300x600dpi (3pass) 275m2/h |
| Printing Speed | 300x800dpi (4pass) 216m2/h |
| Data Interface | External: USB 2.0; Internal: High-speed SCSI cable |
| Working Environment | Temp.23ºC~29ºC, Humidity:50%~80% |
| Software | ONYX / Photoprint... + GZ control console |
| Power | 50Hz/AC, 220V±10%, 27A(Printer) + 380V+10%, 27A(IR Dryer) |
| Packed / Installed Size | LxWxH(mm): Body: 7930 x 1380 x 1960; Taking up: 5860 x 430 x 570 / 7550 x 1800 x 1515 |
| G.W. / N.W. | 3370kgs / 2700kgs |
Print Head
The Starfire 1024 print head with three rows staggered for superior output and piezo variable dot technology. It ensures high-resolution and vibrant & fast printing making it suitable for various digital printing applications.
Ink Supply System
The solvent printer 5.3 meter uses the negative pressure recirculation system for the ink supply with a 5L ink tank size. This system has a pressure balancing unit & pressure protection unit for steady ink flow, lowers ink waste and can accurately control ink usage. It enables color accuracy, easy ink replacement and delivering precise ink quantities.
Drying System
The pre, mid & extended infrared heater cures the media instantly. The pre-IR heater warms the media, mid-IR dries the ink & provides perfect color saturation and the extended IR heater provides additional drying that prevents smudging. It results in vibrant and long-lasting output for the operation with the printer.
Media Delivery System
A multi-roll media feeding system with rubber feeding rollers operates by using multiple rolls of media. It adjusts the roller pressure accordingly to prevent jams or misalignment. It helps for reliable media feeding, continuous operation and rollers ensure precise media advancement.
RIP Software
PhotoPrint RIP software with GZ control console assists in converting digital printer understandable format from the input file. It allows for easy adjustment of print settings and optimizing output for various applications.
