The large format solvent printer is widely used in the graphics & signage industry of digital printing technology. It uses solvent-based ink that is durable & weather-resistant and capable of adhering to a variety of substrates including vinyl, banner, frontlit, backlit and film etc. The ink is designed to withstand exposure to UV radiation, water, harsh weather conditions and the printed graphics remain vibrant and intact for an extended period. The large format printer has a well-designed body frame structure which is used for stable operation and avoids vibrations that could distort print quality.
Model: C3204SG Plus – C3202SG Plus
| Model | C3204SG Plus - C3202SG Plus |
|---|---|
| Print Head | 4 Starfir 1024 - 2 Starfir 1024 |
| Ink | C.M.Y.K solvent / eco-solvent |
| Ink Supply System | GnTek negative pressurerecirculation system |
| Printing Width | Max.3200mm |
| Media Type | Banner, Frontlit, Backlit, Vinyl, Film…... |
| Feeding System | Automatic media feeding and taking up system with air shaft |
| Drying System | Pre, mid post and extended heater plus smart IR dryer |
| Printing Speed | 300x400dpi 234m2/h - 300x400dpi 129m2/h |
| Printing Speed | 600x400dpi 209m2/h - 600x400dpi 115m2/h |
| Printing Speed | 300x600dpi 163m2/h - 300x600dpi 86m2/h |
| Printing Speed | 600x600dpi 146m2/h - 600x600dpi 76m2/h |
| Printing Speed | 300x800dpi 127m2/h - 300x800dpi 67m2/h |
| Printing Speed | 600x800dpi 112m2/h - 600x800dpi 59m2/h |
| Data Interface | External: USB 2.0; Internal: High-speed SCSI |
| Working Environment | Temp.23ºC~29ºC, Humidity:50%~80% |
| Software | PhotoPRINT + GZ control console |
| Power | 50Hz/AC, 220V±10%, 13A(Printer) + 34A(IR Dryer) |
| Installed / Packed Size | LxWxH(mm): 4840 x 1200 x 1530 / 5140 x 1150 x 1150 |
| G.W. / N.W. | 1150kgs / 886kgs |
Print Head
The Dimatiz Starfire 1024 print head assists in printing high-resolution output with accurate details and vibrant colors. It is known for durability, reliability and leading to reduced maintenance & downtime. Compatible with a wide range of substrates or ink types and makes it versatile for various applications.
Ink Supply System
The large format printer has a negative pressure recirculation system containing a balancing unit & pressure protection unit to assure steady ink delivery. It has features that include ink reservoirs, ink level sensors to monitor and a pumping mechanism for controlled ink delivery. It offers automated ink placement to reduce operator intervention.
Drying System
The large format solvent printer is equipped with pre, mid and extended IR heater offers numerous features to dry the media ink. The pre-IR gives ink adhesion by warming up the substrate, mid-IR enhances color vibrancy & cures the ink on the materials and extended IR provides thorough curing & prevents smudging.
Media Feeding System
An automatic media feeding system precisely feeds the material avoiding jams or wrinkles. An air shaft taking up system winds up the media, motor-driven advances to the substrate and an integrated setup enables continuous processing.
RIP Software
PhotoPrint RIP software with a GZ control console acts as an intermediary between the computer and the digital printing machine. It interprets the image files, converts them into a machine understandable format. It adjusts color profiles and resolutions as required.
