The industry-leading hybrid UV printer machine is progressive to make the reproduction of digital images directly onto various material surfaces such as banner, vinyl, backlit, PVC and PET etc. It translates digital files into print without the requirement of traditional printing plates. The versatility of the machine offers swift and high-quality printing which makes it ideal for the signage & advertising business industry. It is very useful for customized printing solutions. It delivers stunning outputs for various industrial applications with a precise bulk ink supply system and white ink recirculation system.
Model: Thunderjet DQ1800UV
| Model | Thunderjet DQ1800UV |
|---|---|
| Print Head | 3~4 Epson I3200 U1 print heads |
| Technology | Piezo ariable dot (Grayscale) |
| Curing System | Duel water cooling LED UV lamps |
| Ink | Flexible UV ink |
| Color Config. | KCMY ; KCMY+W ; W+KCMY + V |
| Ink Supply System | Bulk ink supply system + white ink recirculation system |
| Ink Tank | 1000ml |
| Printing Width | Max.1800mm |
| Media Type | Banner, Vinyl, Backlit textile, leather, PVC film PET film…... |
| Roll Diameter | Max. 300mm |
| Roll Weight | Max. 50kgs |
| Core Diameter | 3 in (76.2mm) or 2 in (50.8mm) |
| Printing Speed Mode | Resolution - Color(3H) - CWC - CWKWC |
| Printing Speed Draft | 720x1200dpi - 46.8m2/h - 20m2/h - 3.9m2/h |
| Printing Speed Production | 720x1200dpi - 41m2/h - 17m2/h |
| Printing Speed Hi-resolution | 720x1800dpi - 32.5m2/h - 11m2/h |
| Printing Speed Photo | 720x1800dpi - 23m2/h - 7.6m2/h |
| Data Interface | External: Ethernet; Internal: Fiber Optical |
| Working Environment | Temp.23ºC~29ºC, Humidity:50%~80% |
| Software | FlexiPRINT / ONYX(Optional)… + GZ Printer Manager |
| Power | Single phase, 50Hz/AC, 220V±10%, 5A(Printer + UV Controller) |
| Packed / Installed Size | LxWxH(mm): 3600 x 1150 x 950 / 3433x 1052 x 1663 |
| N.W. / G.W. | 761kgs / 615kgs |
Print head
The Epson i3200 U1 print head has advanced technology to deliver the droplet of ink with remarkable accuracy and produce high-resolution prints. Its efficient ink delivery system contributes to consistent and reliable end products.
Curing system
This machine uses dual water cooling LED UV lamps that ensure the efficient curing of inks. The advanced technology accelerates production by rapidly drying inks on various substrates to result in vibrant and durable prints. It boosts productivity, reduces energy consumption, operational costs and material wastage.
Piezo Variable Dot Technology
Hybrid UV printer has piezo variable dot technology that allows for the modulation of ink droplet sizes on the printed material. By controlling the droplet sizes, can achieve finer details, smoother gradients, improved color accuracy and smoother tones in prints.
Bulk Ink Supply System
It features a bulk ink supply system with a white ink recirculation system that gives a reliable flow of ink to the print head. It enables longer runs without frequent cartridge changes that enhance productivity. The white ink recirculation system is helpful to print that requires vibrant and opaque white prints.
RIP Software
This hybrid machine is powered by FlexiPRINT/ONYX as RIP software, a versatile solution to improve print processing. With its user-friendly interface, can streamline the workflow and optimize output quality. This seamless integration comes along with the GZ printer manager that offers precise control for efficient production.
