The hot & cold lamination machines ensure permanent finishing, sealing and protection against water & abrasion by laminating it. The popular way to save the media, improves the quality & durability of printed materials and survive in harsh environments. This high-end laminator will suit your business needs, protects from scratches & smudges, avoids the damage of UV light and very less prone to tearing. Hot & cold lamination can handle various widths up to 1520mm & thicknesses up to 20mm and has an infrared heating method.
Model: BPI-1700A
| Model | BPI-1700A |
|---|---|
| Max laminating width | 1400/1520 mm |
| Max laminanting thickness | 20 mm |
| Type | Hot & cold |
| Speed | Upto 7 m / min |
| Max Temp | 120 C / 248 F |
| Pressure/Height Adjust | Air pressure |
| Heated method | infrared |
| Roller | Silicon |
| Preheating time | 10-15 min |
| Power input | 2200 W |
| KW / H | 0.8-1 |
| Volt | 110/220V |
| Emergency button | 2 |
| Laser eye | Yes |
| Lamination Process | Auto & Manual (Pneumatic roller lifting) |
| Power Specification | 220V / 230V 50 / 60 HZ |
| Operational Environment | Temperature 20° C - 40° C Humidity 20% - 80% |
| Roller Type | Hot 7 Cold silicon roller with metal core |
| Dimension Machine | L2000 X W750 X H1200 mm |
| Dimension Package | L2100 X W850 X H1300 mm |
The silicon roller is equipped for both the hot & cold lamination with a metal core that has high-temperature resistance, high flexibility for the material feeding, good tensile to apply the pressure & helps to run at optimal rates to laminate successfully and the film position can adjust by adjustment knob.
The lightweight easy supply & auto-grip supply shafts use for user-friendly material loading, connect the material with a machine, can load the film & adhesives quickly, provides a smooth output lead, has fantastic strength in gripping and prevents from rolling on flat surfaces.
The footswitch is a hand-free operation and also a powerful tool because easy to operate and offers start & stop operation by simple foot press while handling the operation. It has safety sensors on the corners of the machine as an emergency stop to stop the process when there is any crash or error with the machine.
