Our flatbed UV printing machine is designed to print on any flexible materials, enabling continuous printing, rendering prints vibrant and immediately ready for finishing after exposure to UV light. It is using UV curable ink as a specialized ink that cures the ink on the media when exposed to UV light. The drying process results in vibrant and durable prints on various substrates including acrylic, aluminum sheet, foam board, PVC board, leather and glass etc. The printer provides print longevity, scratch resistance, color vibrancy, essential for industries requiring precise printing and makes it ideal for diverse applications.
Model: H0906i32
| Model | H0906EI |
|---|---|
| Print Head | 2~3 Epson I3200 U1 print heads |
| Print Technology | Drop-On-Demand Piezo with Variable Dot |
| Resolution | 720x1200dpi~720x1800dpi |
| Curing System | Four water colling LED UV curing lamps |
| Ink | UV Curable ink |
| Colors Configuration | CMYK; CMYK+W; CMYK+W+V |
| Ink Supply System | Bulk ink supply system with white ink recirculation system |
| Ink Tank | 500ml |
| Media Thickness | Up to 150mm |
| Media Type | Acrylic, Aluminum sheet, Foam board, PVC board, Leather, Glass bottle, Wood, Ceramic tile, etc |
| Printing Size | Max. 900x600mm |
| Printing Speed Draft | 720x1200dpi - Weak - 4.2min/sheet - 4.5min/sheet |
| Printing Speed Production | 720x1200dpi - Medium - 5.0min/sheet - 5.5min/sheet |
| Printing Speed Hi-resolution | 720x1800dpi - Weak - 6.3min/sheet - 6.8min/sheet |
| Printing Speed Photo | 720x1800dpi - Medium - 7.5min/sheet - 8.3min/sheet |
| Data Interface | Gigabit Ethernet |
| Working Environment | Temp.20ºC~30ºC, Humidity: 35%~65% |
| Software | FlexiPRINT Mini UV+GZ control console |
| Power Requirements | Single-phase, AC220V±10%, 50/60Hz,, 10A |
| Power Consumption | Printer: Approx. 1100W; UV controller: Approx. 800W |
Installation/Package Dimension | LxWxH(mm): 2180x1565x1371 / 2300x1770x1600 |
| N.W./G.W. | 492kgs/690kgs |
Print Head
The Epson i3200 U1 print head helps to produce high-resolution prints and advanced nozzle technology ensures accurate color reproduction. It maintains consistent performance, contributing to quality output and gives impact on overall print end product.
Piezo With Variable Dot
Utilizing drop-on-demand piezo with variable dot technology precisely expels ink droplets and enables intricate tonal variations and fine details. This innovation ensures optimal ink distribution, resulting in lifelike prints and supports diverse substrates.
Curing System
The flatbed UV printing machine incorporates four water cooling LED UV lamps as a curing system offers efficient curing of UV inks and coatings. It helps to maintain optimal temperature levels, allows for faster production levels, reduced energy consumption and consistent curing across the media surface.
Ink Supply System
The bulk ink supply system with white ink recirculation enables continuous printing with large ink volume and reduces downtime for ink replacement. The white ink recirculation system protects head clogging and prints on dark substrates. This dynamic combination optimizes workflow and extends head life.
RIP Software
The FlexiPRiNT RIP software with a GZ control console supports a wide range of printers, can use a wide format of files. With intuitive interfaces & powerful tools, empowers users to achieve high-quality output. The large format printing industry can achieve superior output, cost savings and streamlined workflows.
