The flatbed LED UV printer has the capacity to produce large-format prints on a diverse array of substrates. The built-in heater gives optimal printing conditions by regulating the temperature of the print environment, proper ink adhesion and color consistency. The negative pressure system aids in ink delivery, removal of excess ink or air bubbles, creates a controlled droplet ejection and enhances the output quality. Utilizes the optional CPS (Camera Positioning System) for precise alignment, especially on irregularly shaped items. The optional clyinder printing kit extends the machine’s capability to print on custom branding curved surfaces.
Model: H1612GI
| Model | H1612GI |
|---|---|
| Print Head | 2~4 Ricoh G5i print heads |
| Print Technology | Drop-On-Demand Piezo with Variable Dot |
| Resolution | 720x600dpi~720x1200dpi |
| Curing System | Four water cooling LED UV curing lamps |
| Ink | UV curable ink |
| Color Configuration | 1xW+2xKCMY; 1xW+2xKCMY+1xV; 4xKCMY |
| Ink Supply System | Bulk ink supply system with white ink recirculation system |
| Ink Tank | 1000ml |
| Media Thickness | Up to 150mm |
| Media Type | Acrylic, Aluminum sheet, Foam board, PVC board, Leather, Glass bottle, Golf ball, Wood, Ceramic tile, Souvenir, Toys, etc |
| Printing Size | Max. 1600 x 1200mm |
| Printing Speed Mode | Resolution - 1xW+2xKCMY - 1xW+2xKCMY+1xV - 4xKCMY |
| Printing Speed Draft | 720x600dpi - 10.7m2/h - 107m2/h - 32.3m2/h |
| Printing Speed Production | 720x900dpi - 7.8m2/h - 7.5m2/h - 26.1m2/h |
| Printing Speed Hi-resolution | 720x900dpi - 6.8m2/h - 6.2m2/h - 21.3m2/h |
| Printing Speed Photo | 720x1200dpi - 5.5m2/h - 5.3m2/h - 8.2m2/h |
| Data Interface | Gigabit Ethernet |
| Working Environment | Temp.20ºC~30ºC, Humidity:35%~65% |
| Software | FlexiPRINT Mini UV + GZ control console |
| Power Requirement | Single-phase, AC220V+10%, 50/60Hz, 10A |
| Power Consumption | Printer: Approx. 1100W; UV controller: Approx. 800W; Vacuum blower: 2200W |
| Packed / Installed Size | LxWxH(mm): 3620 x 2280 x 1750 / 3310 x 2055 x 1467 |
| G.W. / N.W. | 1160kgs / 800kgs |
Print Head
The Ricoh G5i print head employs an advanced variable dot technology that precisely deposits ink onto print media. The head gives high-resolution capabilities, rapid printing speeds, durability and is suitable for a wide range of applications.
Variable Dot Technology
The flatbed LED UV printer has drop on demand piezo variable dot technology accurately controls ink drop formation and size. It offers variable dot sizes, enabling the reproduction of fine details and gradients with exceptional precision. It optimizes ink usage, is cost-efficient, produces smooth transitions and vibrant images.
Curing System
The four water cooling LED UV curing system with flatbed UV printer instantly cure UV inks on the printed substrate. It prevents overheating, has high performance and prolongs the lamp’s lifespan. Provides efficient curing across the entire print area, ensures fast drying. The LED UV technology is eco-friendly, energy-efficient, has a long lamp lifespan and reduces operating costs.
Ink Supply System
The bulk ink supply with a white ink recirculation system of a flatbed LED printer facilitates uninterrupted printing by providing a large ink reservoir. The white ink system circulating the ink prevents pigment settling and clogging by continuously agitating the ink.
RIP Software
The Flexiprint RIP software with the GZ control console is a powerful combination that translates design files into printable data. The control console provides an intuitive interface that manages and monitors the process, ensuring workflow customization.
