Fiber Laser Cutting Machine

Cuts The Material With Precise Detail

The D-soar plus ultra high power fiber laser cutting machine outputs high power laser beam to focus on the surface of materials such as stainless steel , carbon steel, copper, aluminum, nickel, manganese & other metal types, controlled by numerical & mechanical systems and achieves the automatic cutting by moving the laser head with fast speed & high accuracy. In the laser cutting machine, the constant temperature water cooling system eliminates the heat, creates the desired temperature and keeps it constant all the time to produce quality end products.

Laser Power: 8000W – 20000W

Functions & Features

The fiber laser source generates a laser beam & delivering it at the same time, transmits the beam over the cutting head, has high energy efficiency, helps in difficult machining conditions, causes instant melting or evaporation and allows extreme results.
The integrated shuttle table in the fiber laser cutting machine is an excellent solution for loading & unloading the material and can load the workpiece while another is being cut without making interruption. It saves time, automates the material handling and significantly improves the throughput of the machine.
The narrow cutting seam, a minimum head-affected zone without burrs, a non-contact process in that head does not touch the metal surface and will not scratch the workpiece. It protects the end product from local deformation, has good processing flexibility, processes any complex graphics precisely and the nozzle being avoids polluted by slag produced during the cutting.

Technical Specification

Model	D-SOAR-PLUS
Laser Source	IPG Fiber Laser Source
Laser Power	8000W 10000W 12000W 15000W 20000W
X-axis Gantry	High Speed Gantry
Working Table	Hydraulic Shuttle Table (optional)
Working Stroke	2000x4000 / 2500x6000 / 2000x6000 / 2500x8000mm (actual size shall be prevail)
Max. Cutting Speed	Depending on metal type and thickness
Power Supply	380V/50Hz/60Hz/60A
CNC system	EtherCAT Bus Controlling System
Footprint Size	9000x5000mm as per the working stroke of 1500x3000mm

Stability 95%

Cutting Accuracy 99.99%

Durability 97%

Major Components

Fiber Laser Source

IPG (Germany)

Industrial Guide Rail

PMI (France)

Servo Motors & Drives

Schnieder (France)

Hellical Rack & Gear

WMH (Switzerland)

Planetary Gearbox

Neugart (Germany)

Electric Relay System

Schnieder (France)

DNE Bsytronic Head

Bystronic (Swiss)

Components of The Machine

Laser Source
The fiber laser source utilizes a laser source that generates the fiber optics. This advanced technology enables efficient laser beams to cut the material. The resulting beam exhibits exceptional intensity, delivers precise and swift cutting capabilities.

Guide Rail
The industrial guide rail is the crucial component to control the motion, ensures precise and stable movement of the laser head with the designated cutting path. It contributes to the machine’s accuracy, facilitating consistent processing, speed and overall reliability.

Servo Motors & Drives
Servo motors and drives assist in achieving precise and dynamic motion control. It converts electrical signals into mechanical movement and also guides the laser head with accuracy. Ensures rapid & smooth transitions during the processing operation and the reliability enhances the overall performance.

Gantry
Gantry is the supporting structure that is made up of aviation aluminum open steel by die-casting making it more rigid and handling the entire operation with faster acceleration.

Bus Controlling System
The customized bus controller system helps to instruct the cutting requirements, provides reliable operation, enriched function settings and facilitates rapid troubleshooting.

Fiber Laser Head
The fiber laser cutting head with its optical & autofocusing system brings the ability to cut the material with a precise laser beam and makes the complex cutting process simpler.

Machine Frame
The balanced frame structure of the product involves the annealing treatment to increase the ductility & machinability, improves the workability of the material and gives error-free operation.

Control Unit
Fiber laser cutting machine has a high-end control system to simplify the cutting operation, handle the required parts to be processed in an effective manner and achieve any complex pattern. The laser indicating system ensures the beam level at the right position, featuring aim by red light indication and enhancing the overall operating experience.
