The eco solvent printer utilizes an advanced Epson printhead to bring graphics that are precisely detailed with high resolution. The intelligent synchronous vacuum system is a technology that optimizes media handling. It has the ability to adapt to varying print conditions to achieve superior results. An automatic media cutter precisely cuts the printed material to the desired size or shape. It eliminates the need for manual trimming, reduces labor requirements and ensures clean cuts, resulting in professionally finished products.
Model: Thunderjet AQ1804S PRO
| Model | Thunderjet AQ1804S PRO |
|---|---|
| Print Head | 4 x Epson I3200 print heads |
| Ink | EPI2-2 years durability eco solvent ink |
| Colors Config. | KCMY |
| Ink Supply System | 2L Bulk ink system with ink cartridges |
| Printing Width | Max. 1800mm |
| Media Type | Banner, Coated PP, Vinyl, PVC film…... |
| Roll Weight | Max. 50kgs |
| Core Diameter | 3 in (76.2mm) or 2 in (50.8) |
| Drying System | 3-way heater and IR Dryer |
| Printing Speed Draft | 360x1800dpi - 94m2/h |
| Printing Speed Production | 720x1200dpi - 79m2/h |
| Printing Speed High-res | 720x1200dpi - 57m2/h |
| Printing Speed Photo | 720x1800dpi - 49m2/h |
| Data Interface | External: Ethernet; Internal: Fiber Optical |
| Working Environment | Temp.23ºC~29ºC, Humidity:50%~80% |
| Software | FlexiPRINT / ONYX (Optional)... + GZ Printer Manager |
| Power | Single phase, 50Hz/AC, 220V±10%, 6.7A (Printer) + 16.7 (IR Dryer) |
| Installed Size | LxWxH(mm): 3102 x 1012 x 1717 |
| N.W. / G.W. | 348kgs / 480kgs |
Print Head
The Epson i3200 print head has the capability to handle a wide range of materials for vibrant prints & long-lasting results. With its advanced technology, it gives high reliability, durability, flexibility and suits for various applications.
Drying System
The three way heater and IR dryer of the eco solvent machine rapidly cure the ink, expediting the drying process and allowing for immediate handling & finishing. The IR dryer emits infrared heat to minimize the drying time and this combination ensures vibrant colors, quick & efficient production.
Capping & Wiping System
The optimized capping and wiping system of eco solvent printer consists of precise caps & wipers to protect the print head when not in use. It prevents clogs, nozzle blockage, keeps the nozzles clean and the ink flow is smooth. Also, minimizes maintenance, lowers material waste and reduces downtime.
Pinch Rollers
The electric drive pinch rollers with adaptive pressure are used to grip the printing substrate securely. This eco solvent machine has adjustable pressure that ensures proper media tension and prevents misalignment or skewing during the operation. It provides stability, allowing for consistent processing for large-format output, smooth media advancement and contributing to overall quality.
Variable Dot Technology
The advanced piezo variable dot technology (Greyscale) permits control over ink droplet size, enabling variable dot sizes. It produces smaller or bigger drops required with fine details and richer colors. It is essential to achieve smooth gradients and is ideal for high-quality graphics & signage applications.
AR Taking System
The eco solvent printer has an AR taking up system that efficiently manages the printed material. It automatically rolls up, maintaining proper tension and alignment. It prevents media from sagging, wrinkling, or accumulating on the floor and ensuring organized workflow.
RIP Software
The FlexiPRINT/Onyx RIP software with GZ print manager delivers high-resolution print with exceptional color accuracy. This technology converts a printer’s understandable form from the input design file and handles a wide range of media effectively.
